Brands |
N/A EDAC |
Series |
N/A 140 |
Electrical Connector Type |
N/A Contact |
Electrical Connector Mounting |
N/A In-Line Wire to Board |
Electrical Connector Gender |
N/A Female Male |
Number of Positions |
N/A 3 |
Material |
N/A Polyamide 66 (PA66), Underwriters Laboratories (UL) 94V-0 |
Color |
N/A Natural |
Pitch |
N/A 2.0 mm |
Entry Type |
N/A Top Entry |
Insulator Material |
N/A Polyamide 66 (PA66), Underwriters Laboratories (UL) 94V-0 |
Contact Material (Male) |
N/A Brass |
Contact Material (Female Pin) |
N/A Phosphor Bronze |
Contact Plating (Male) |
N/A Tin Plating |
Contact Plating (Female Pin) |
N/A Tin with Copper Underplating |
Current Rating |
N/A 2 A |
Maximum Initial Contact Resistance |
N/A 10 mO |
Dielectric Withstanding Alternating Current (AC) Root Mean Square (RMS) Voltage |
N/A 800 V |
Minimum Insulation Resistance |
N/A 1000 MO |
Operating Temperature |
N/A -40 to +105 ºC |
Voltage Rating |
N/A 100 V |
Applicable Wire |
N/A 30 to 24 AWG |
Note |
N/A Brochures and handouts are also available in Spanish, Portuguese, French, and Chinese, and to visit WWW.EDAC.NET! to download. |
