Brands |
N/A EDAC |
Series |
N/A 628 (Plastic) |
Electrical Connector Type |
N/A D-Sub |
Electrical Connector Gender |
N/A Receptacle (Socket) |
Body Material |
N/A Plastic |
Number of Positions |
N/A 15 |
Color |
N/A Black |
Contact Description |
N/A Press Fit Contact |
Insulator Style |
N/A Standard Profile |
Shell Plating |
N/A Nickel Plated Shell |
Flange Mounting Option |
N/A #4-40 Threaded Standoff with Boardlocks |
Insulator Material |
N/A Underwriters Laboratories (UL) 94V-0, Chemical Resistant Thermoplastic Polyester |
Contact Material (Plug (Pins)) |
N/A Brass |
Contact Material (Receptacle (Socket)) |
N/A Brass |
Contact Plating Note |
N/A Selective Gold Over Nickel for the Mating Area Tin Plating for Tail Area |
Contact Plating |
N/A Gold Flash Plating |
Current Rating Per Contact |
N/A 3 to 5 A |
Maximum Contact Resistance |
N/A 25 mO |
Dielectric Withstanding Alternating Current (AC) Root Mean Square (RMS) Voltage at Sea Level |
N/A 1000 V |
Minimum Insulation Resistance |
N/A 1000 MO |
Operating Temperature |
N/A -55 to +85 ºC |
Maximum Mating Force Per Contact Position |
N/A 16 oz4.45 N |
Minimum Unmating Force Per Contact Position |
N/A 1 oz0.28 N |
Ferrite Loss at 30 Megahertz (MHz) Frequency |
N/A 20 dB |
Ferrite Loss at 50 Megahertz (MHz) Frequency |
N/A 30 dB |
Ferrite Loss at 100 Megahertz (MHz) Frequency |
N/A 50 dB |
Shell Material |
N/A Nickel Plated Steel (Optional Tin plating) |
Note |
N/A Brochures and handouts are also available in Spanish, Portuguese, French, and Chinese, and to visit WWW.EDAC.NET! to download. |
